Ningbo VET Energy Technology Co., Ltd. သည် တရုတ်နိုင်ငံတွင် တည်ထောင်ထားသော အဆင့်မြင့်နည်းပညာလုပ်ငန်းတစ်ခုဖြစ်ပြီး၊ ကျွန်ုပ်တို့သည် Pem Fuel Supplier အတွက် Graphite Bipolar Plate.we အတွက် ပရော်ဖက်ရှင်နယ် Graphite Bipolar Plate.we သည် ပစ္စည်းနည်းပညာအသစ်နှင့် မော်တော်ယာဥ်ထုတ်ကုန်များကို အာရုံစိုက်လျက်ရှိပါသည်။
We have developed cost- effective graphite bipolar plates for PEMFC which requires the use of advanced bipolar plates with high electrical conductivity and good mechanical strength. Our bipolar plates allow fuel cells to operate at high temperatures and have excellent electrical and thermal conductivity.
ဟိPem Fuel Supplier Graphite Bipolar Plate အတွက် Graphite Bipolar Plate တရုတ်နိုင်ငံတွင် ထုတ်လုပ်သူနှင့် ပေးသွင်းသူများထဲမှ တစ်ခုဖြစ်သည့် Vet Energy မှ တရုတ်နိုင်ငံတွင် ထုတ်လုပ်သည်။ ဝယ်ပါ။Pem Fuel Supplier Graphite Bipolar Plate အတွက် Graphite Bipolar Plate ကျွန်ုပ်တို့၏စက်ရုံမှစျေးနှုန်းချိုသာသည်။ ကျွန်ုပ်တို့တွင် ကျွန်ုပ်တို့၏ကိုယ်ပိုင်အမှတ်တံဆိပ်များရှိပြီး အများအပြားကိုလည်း ပံ့ပိုးပေးပါသည်။ သင်ကျွန်ုပ်တို့၏ထုတ်ကုန်များကိုစိတ်ဝင်စားလျှင်, ငါတို့သည်သင်တို့ကိုချိုသာသောစျေးနှုန်းပေးမည်။ ကျွန်ုပ်တို့ထံမှ အသစ်အဆန်းနှင့် အရည်အသွေးမြင့်သည့် လျှော့စျေး ကုန်ပစ္စည်းကို ဝယ်ယူရန် ကြိုဆိုပါသည်။
အင်္ဂါရပ်များ:
- ဓာတ်ငွေ့များ ( ဟိုက်ဒရိုဂျင် နှင့် အောက်ဆီဂျင် ) ကို မစိမ့်ဝင်နိုင်ပါ။
- စံပြလျှပ်စစ်စီးကြောင်း
- လျှပ်ကူးမှု၊ ခွန်အား၊ အရွယ်အစားနှင့် အလေးချိန်အကြား ဟန်ချက်ညီမှု
- သံချေးတက်ခြင်းကို ခံနိုင်ရည်ရှိခြင်း။
- အမြောက်အများထုတ်လုပ်ရန်လွယ်ကူသောအင်္ဂါရပ်များ:
- ကုန်ကျစရိတ်သက်သာခြင်း။
Graphite အဆင့် |
||||||||
ပစ္စည်းအမည် |
နံပါတ် |
အစုလိုက် |
သတ်သတ်မှတ်မှတ် ခုခံမှု |
Flexural ခွန်အား |
Compressive ခွန်အား |
Ash မက်တယ်။ |
အမှုန်အမွှားအရွယ်အစား |
လုပ်ဆောင်နေသည် |
g/cm3 |
μΩm |
Mpa |
Mpa |
% |
မက်တယ်။ |
|
||
Electrode Graphite |
VT-RP |
≥၁.၅၅~၁.၇၅ |
၇.၅~၈.၅ |
≥8.5 |
≥20 |
≤0.3 |
≤8 ~ 10 မီလီမီတာ |
Impregnation ရွေးချယ်နိုင်သည် |
တုန်ခါမှု ဂရပ်ဖစ် |
VTZ2-3 |
≥1.72 |
၇~၉ |
≥13.5 |
≥35 |
≤0.3 |
≤0.8 မီလီမီတာ |
Impregnation နှစ်ခု မုန့်ဖုတ်သုံးမျိုး |
VTZ1-2 |
≥1.62 |
၇~၉ |
≥9 |
≥22 |
≤0.3 |
≤2 မီလီမီတာ |
Impregnation တစ်ခု Baking နှစ်ခု |
|
Extruded Graphite
|
VTJ1-2 |
≥1.68 |
၇.၅~၈.၅ |
≥19 |
≥38 |
≤0.3 |
≤0.2 မီလီမီတာ |
Impregnation တစ်ခု Baking နှစ်ခု |
ပုံသွင်းထားသော Graphite |
VTM2-3 |
≥1.80 |
၁၀~၁၃ |
≥40 |
≥60 |
≤0.1 |
≤0.043 မီလီမီတာ |
Impregnation နှစ်ခု မုန့်ဖုတ်သုံးမျိုး |
VTM3-4 |
≥1.85 |
၁၀~၁၃ |
≥47 |
≥75 |
≤0.05 |
≤0.043 မီလီမီတာ |
Impregnation သုံးခု မုန့်ဖုတ်လေးခု |
|
Isostatic Graphite |
VTD2-3 |
≥1.82 |
၁၁~၁၃ |
≥38 |
≥85 |
≤0.1 |
2μမီတာ၊ ၆μမီတာ၊ ၈μမီတာ၊ ၁၅μm စသည်တို့… |
Impregnation နှစ်ခု မုန့်ဖုတ်သုံးမျိုး |
VTD3-4 |
≥1.88 |
၁၁~၁၃ |
≥60 |
≥100 |
≤0.05 |
≤0.015 မီလီမီတာ |
Impregnation သုံးခု မုန့်ဖုတ်လေးခု |
